900TVL
Product features：
- 256 spots, 8 line scan, Xie Yi, movement control Xie Yi automatic.
- The guard bit, soft address, timing, tracking function
- Power recovery, protection class IP66
- Ultra low power consumption, strong stability
- OSRAM array lamp, infrared distance 100M
|
Category |
Parameter |
|
Item Number |
JW-PC631-H |
|
The imaging source |
1/3"CMOS |
|
Effective pixels |
900TVL |
|
Resolution |
900TVL |
|
Minimum illumination |
Color: 0.01Lux@F1.2 0 LUX; Black: 0.001Lux@F1.2 0 LUX |
|
Signal to noise ratio |
＞50db |
|
Backlight compensation |
on/off |
|
The white balance |
auto |
|
Protocols |
PELCO-D PELCO-P |
|
Interface Standards |
RS485 BUS |
|
The focal length |
4.7～94mm |
|
Optical zoom |
30x |
|
Pan/Tilt rotate speed |
Pan：0°～30°/s;Tilt：0°～20°/s |
|
Pan/Tilt rotate angle |
Pan：0-360°；Tilt: 0-90° |
|
Preset |
255 |
|
Signal System |
AHD/TVI/CVI/CVBS |
|
Weight |
3.2kg |
|
Power Input |
DC12V |
|
The work environment |
Working temperature：-35℃～50℃，Working humidity：≤90％ |
|
Protection grade |
IP66 |
JW-PC631-H 30X 6" Analog IR PTZ
- Brands JETWAY
- Product Code: JW-PC631-H 30X 6" Analog IR PTZ
- Availability: 100
-
¥830.00
